IGBT Static Voltage Stabilizer

IGBT-Based Static Voltage Stabilizer

Solid-state voltage regulation using high-speed IGBT power converters designed for fast correction, high reliability, and zero mechanical wear.

Product Overview

VQNIX IGBT Static Voltage Stabilizers provide instantaneous voltage correction using PWM-controlled IGBT power stages. Unlike servo stabilizers, these systems have no moving parts, ensuring high reliability and fast response for critical industrial loads.

Key Features

Correction time < 10 ms
Wide input voltage range
High efficiency (> 97%)
No mechanical components
Microcontroller-based digital control
Over-voltage, under-voltage & short-circuit protection

System Block Diagram

The block diagram below shows the power and control architecture of the IGBT-based static voltage stabilizer.

IGBT Static Voltage Stabilizer Block Diagram

Applications

EV Charging Stations
Grid-Tie Inverters (GTI)
CNC & Automation Systems
Medical Equipment
Data Centers
Critical Industrial Loads

Technical Specifications

Parameter	Value
Input Voltage	±15% to ±35% (configurable)
Output Voltage	230V / 415V ±1%
Response Time	< 10 ms
Power Rating	5 kVA to 500 kVA
Topology	IGBT-based PWM AC-AC Converter
Cooling	Forced Air / Optional Liquid Cooling
